QIAOSHI (CHINA) INTERNATIONAL TRADE LIMITED
welded mesh machine

HTD-A
  • Peculiarity:
    Box-style support, high stability, lower noise. E-Machine in one, straighten and send wire automatically. Especially the wire of hard materials.

Diameter of wire (mm) 0.4-1.2 Speed 120/min
Size of mesh (inch) 1/2; 1/4; 1; 2. Weight(kgs) 1800
Width (mm) 600; 914; 1000; 1220 Out size 2500*1500*1200

HTD-B
  • Peculiarity:
    Box-style support, high stability, lower noise. E-machine in one, straighten and send wire after cutting automatically. Use of directional pillory and wire rack makes the machine more smart and labor-saving.

Diameter of wire (mm) 1.0-2.5 Speed 90/min
Size of mesh (inch) 1; 2; 4; Weight(kgs) 3000
Width (mm) 914;1000;1220;1500;1800 Out size 3100*1700*1400

HTD-C
  • Peculiarity:
    Adopt indirect-welding technology; squeeze once while welding divided in several times. We have the capability to make different orifices between wefts in the same plate. Synchronous control system, welding time and separate control with PCL digital programming system, touch-screen input and panel button all allow us to make the operation more intelligent and rational.

Diameter of wire (mm) 3-5 Speed 30/min
Size of mesh (inch) 50*50-300*300 Weight(kgs) 3000
Width (mm) 2000 Out size 6000*3200*1800

HTD-D
  • Peculiarity:
    We designed it for poultry cages, this machine can produce mesh to long and short automatically, with different orifices in the same plate, two engine frames available.

Diameter of wire (mm) 1.5-3.0 Speed 56/min
Size of mesh (inch) 5*5-50*200 Weight(kgs) 2000-2500
Width (mm) 1200-2500 Out size 2000*1800*1400
CUTLINE

welded-mesh-machine welded-mesh-machine welded-mesh-machine
welded-mesh-machine
