Expanded Mesh Machine

INFORMATION
  • Feature:
    The machines are used for punching shear the cold crimped engine bed with the thickness of 1.2- 2.5mm the width of 2000mm Material strength of 450N/mm2, The specifications of punching shear are su-eyed by the bit of TB5-20 mesh grid plate: If the TB TL is changed the punching shear knife is also changed: TB.TL is increased. The punching shear strength is reduced: TB.TL is reduced. the punching shear strength is increased In order not to damage components for the excess load The nominal tonnage is 63T lf TB TL are reduced the punching shear strength surpasses the nominal tonnage. You can reduce the material thickness and width.
CUTLINE

Main Parameter
TYPE H25-6.3 H25-16 H25-25 H25-63A H25-63B SH25-160A SH25-160B
DEPTH 1.0mm 1.0mm 1.5mm 2.5mm 3mm 6mm 3mm
WIDTH 500mm 1000mm 1250mm 2000mm 2000mm 2500mm 2500mm
TIMES 80/min 50/min 50/min 0/min 5/min 0/min 0/min
DISTANCE 0-1.15mm 0-1.2mm 0-1.2mm 0-4mm 0-4mm 0-7mm 0-7mm
LENGTH OF MESH =20mm =25mm =30mm =100mm =200mm =250mm =250mm
MOTOR 2.2KW 3KW 4KW 11KW 11KW 22KW 22KW
WEIGHT 0.95T 2T 3T 10T 10T 18T 20T
MEASUREMEENT 950 *570 *1780 1800 *1320 *1550 1940 *1600 *2010 2400 *3500 *2300 2400 *3500 *2300 5500 *1750 *3300 5500 *1750 *3300

SERIES STRAIGHTER AHJ TYPE SHJ-05 SHJ-10 SHJ-125 DEPTH=3MM
SERIES STRAIGHTER AHJ DEPTH=3MM 500mm 1000mm 1250mm DEPTH=3MM
CUTLINE

expanded mesh machine expanded mesh machine
