Razor Barbed Wire Machine

INFORMATION
  • Output of 24 hours:
    500kgs. It is equipped with cutters of 5 different shapes.
  • Razor barbed wire coil diameter:
    450mm; 500mm; 700mm; 960mm.
  • Razor barbed wire material:
    Galvanized wire and stainless steel wire.
CUTLINE

A1 Blade Style Thickness:0.5mm
Wire Dia.:2.5mm
Barb Length:10mm
Barb Width:13mm
Barb Spacing:26mm
A2 Blade Style Thickness:0.5mm
Wire Dia.:2.5mm
Barb Length:20mm
Barb Width:15mm
Barb Spacing:33mm
A3 Blade Style Thickness:0.5mm
Wire Dia.:2.5mm
Barb Length:15mm
Barb Width:15mm
Barb Spacing:33mm
A4 Blade Style Thickness:0.5mm .
Wire Dia.:2.5mm
Barb Length:22mm
Barb Width:16mm
Barb Spacing:36mm
A5 Blade Style Thickness:0.6mm
Wire Dia.:2.5mm
Barb Length:60mm
Barb Width:22mm
Barb Spacing: 102mm

Coil Dia.(mm) 500 700 960 450
Number of Circles 56 72 52 33
Standard Covered Length (m) 8-9 11-13 8-10 8
Maximal Covered Length 12 15 13 12
Diameter, Screen Wire 2.5-3mm Material, Screen Wire, Barbed wire Low Carbon Steel Wire, Thermo-Plated with Zinc
Diameter, Wire for Barbs 2-2.5mm Total Weight 1500kgs
Barb Pitch Spacing 3,4,5,6in Power of Motor 3kw

Razor barbed wire machine
Razor Barbed Wire Machine A
Demo Video A
Razor barbed wire machine
Razor Barbed Wire Machine B
Demo Video B
In addition to these products, we also manufacture Razor Barbed Wire which produce them.
