Barbed Wire Machine
Instruction of Double Twisted Barbed Wire Machine
- Use and capability:
FLD/T343-requires the common hot dipped galvanized low carbon steel wire. The products can be used in the national defense, railroad, highway, stockbreeding and agriculture and so on.
FLD-A barbed wire machine is made up by spool wire and twist wire two parts. The machine can produce all kinds of barbed wires. At present, just this kind of machine can produce the barbed wire mesh.
This machine is easy for operation, with low noise, less cost of energy. A kind of digital controlled machine to produce straight and reverse twisted barbed wire.
CUTLINE
| Gauge of Strand and Barb in B.W.G. |
Barbs spacing 3" |
Barbs spacing 4" |
Barbs spacing 5" |
Barbs spacing 6" |
| 12×12 |
6.0617 |
6.7590 |
7.2700 |
7.6376 |
| 12×14 |
7.3335 |
7.9051 |
8.3015 |
8.5741 |
| 12-1／2×12-1／2 |
6.9223 |
7.7190 |
8.3022 |
8.7221 |
| 12-1／2×14 |
8.1096 |
8.841 |
9.2242 |
9.5620 |
| 13×13 |
7.98.8 |
8.899 |
9.8721 |
10.7146 |
| 13×14 |
8.8448 |
9.6899 |
10.2923 |
10.7146 |
| 13-1／2×14 |
9.6079 |
10.6134 |
11.4705 |
11.8553 |
| 14×14 |
104569 |
11.6590 |
12.5423 |
13.1752 |
| 14-1／2×14-1／2 |
11.9875 |
13.3671 |
14.3781 |
15.1034 |
| 15×15 |
13.8927 |
15.4942 |
16.6666 |
17.5070 |
| 15-1／2×15-1／2 |
15.3491 |
17.1144 |
18.4060 |
19.3386 |
| diameter, screen wire |
2.5-3mm |
Material, screen wire and barbed wire |
Low carbon steel wire, thermo-plated with zinc |
| Diameter, wire for barbs |
2-2.5mm |
total weight |
1500 kgs |
| Barb pitch spacing |
3,4,5,6in |
power of motor |
3 kw |
In addition to these products, we also manufacture Barbed Wire which produce them.
|
